Light Curtains For Industrial Safety Applications
Safety Light curtains are electro sensitive devices using one or more light beams, emitted by an Emitter and received by a Receiver, to create an intangible controlled area.
Main characteristics of Light Curtains
![](https://reer-stage.reersafety.com/wp-content/uploads/2021/08/liv_sicurezza.png)
SAFETY LEVEL
Defines the self-monitoring and safety principles contained in the device; it must be chosen as a function of the risk level characterising the machine.
![](https://reer-stage.reersafety.com/wp-content/uploads/2021/08/altezza_protetta.png)
PROTECTED HEIGHT
This is the height protected by the light curtain. If it is positioned horizontally, this value shows the depth of the protected zone.
![](https://reer-stage.reersafety.com/wp-content/uploads/2021/08/portata.png)
RANGE
This is the maximum working distance that may exist between the emitter and the receiver.
![](https://reer-stage.reersafety.com/wp-content/uploads/2021/08/tempo_risp.png)
RESPONSE TIME
This is the time it takes for the safety light curtain to transmit the alarm signal from the time the protected zone is interrupted.
![](https://reer-stage.reersafety.com/wp-content/uploads/2021/08/risoluzione.png)
LIGHT CURTAIN RESOLUTION
The resolution of a light curtain is the minimum size of an object that, placed into the controlled area, will obscure the controlled zone and hence stop the hazardous movement of the machine.
The features of our safety Light curtains
PROTECTED HEIGHT
![PROTECTED HEIGHT](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Altezza_EOS-16.png)
PROTECTED HEIGHT
![PROTECTED HEIGHT](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Altezza_ADMIRAL-8.png)
PROTECTED HEIGHT
![PROTECTED HEIGHT](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Altezza_Safegate-6.png)
PROTECTED HEIGHT
![PROTECTED HEIGHT](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Altezza_Janus-4.png)
PROTECTED HEIGHT
![PROTECTED HEIGHT](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Altezza_EOS-16.png)
PROTECTED HEIGHT
![PROTECTED HEIGHT](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Altezza_Vision-3.png)
![EDM](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
EDM
![Automatic or Manual Start/Restart](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Automatic or Manual Start/Restart
![Cascade connection](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Cascade connection
![Muting Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Muting Function
![Blanking Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Blanking Function
![Integrated Muting Lamp](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Integrated Muting Lamp
![EDM](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
EDM
![Automatic or Manual Start/Restart](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Automatic or Manual Start/Restart
![Cascade connection](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Cascade connection
![Muting Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Muting Function
![Blanking Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Blanking Function
![Integrated Muting Lamp](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Integrated Muting Lamp
![EDM](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
EDM
![Automatic or Manual Start/Restart](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Automatic or Manual Start/Restart
![Cascade connection](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Cascade connection
![Muting Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Muting Function
![Blanking Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Blanking Function
![Integrated Muting Lamp](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Integrated Muting Lamp
![EDM](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
EDM
![Automatic or Manual Start/Restart](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Automatic or Manual Start/Restart
![Cascade connection](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Cascade connection
![Muting Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Muting Function
![Blanking Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Blanking Function
![Integrated Muting Lamp](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Integrated Muting Lamp
![EDM](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
EDM
![Automatic or Manual Start/Restart](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Automatic or Manual Start/Restart
![Cascade connection](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Cascade connection
![Muting Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Muting Function
![Blanking Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Blanking Function
![Integrated Muting Lamp](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Integrated Muting Lamp
![EDM](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
EDM
![Automatic or Manual Start/Restart](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Automatic or Manual Start/Restart
![Cascade connection](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Cascade connection
![Muting Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/true.png)
Muting Function
![Blanking Function](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Blanking Function
![Integrated Muting Lamp](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/close.png)
Integrated Muting Lamp
SPECIAL VERSION
PRES, TEXTILE | Resistant to high vibrations |
---|---|
WTF and WTHF | IP69K certified, Ecolab food-graded watertight housing |
ATEX | Safety light curtains for explosive atmosphere |
SPECIAL VERSION
LONG RANGE | Max. range up to 60 meters |
---|---|
DUAL BEAM | For outdoor applications (max. range up to 80 meters) |
WT and WTH | With IP67 protection rate watertight housing |
SPECIAL VERSIONS
LONG RANGE | Max. range up to 80 meters |
---|---|
LONG RANGE ILP | With integrated laser pointer |
SPECIAL VERSIONS
LONG RANGE | Max. range up to 80 meters |
---|---|
LONG RANGE ILP | With integrated laser pointer |
SPECIAL VERSIONS
PRES, TEXTILE | Resistant to high vibrations |
---|---|
WTF and WTHF | IP69K certified, Ecolab food-graded watertight housing |
SPECIAL VERSIONS
LONG RANGE | Max. range up to 60 meters |
---|---|
WT and WTH | With IP67 protection rate watertight housing |
RANGE
![RANGE](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Range_EOS-10.png)
RANGE
![RANGE](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Range_ADMIRAL-4.png)
RANGE
![RANGE](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Range_SAFEGATE-3.png)
RANGE
![RANGE](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Range_JANUS-3.png)
RANGE
![RANGE](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Range_EOS-10.png)
RANGE
![RANGE](https://reer-stage.reersafety.com/wp-content/uploads/2021/02/Range_VISION-2.png)
SAFETY LEVEL![]() Type 4 - PL e - SIL 3 - | IP RATING![]() IP65 IP67 IP69K |
CROSS SECTION | 30 x 28 mm |
SAFETY LEVEL![]() Type 4 - PL e - SIL 3 - | IP RATING![]() IP65 IP67 IP69K |
CROSS SECTION | 45 x 35 mm |
SAFETY LEVEL![]() Type 4 - PL e - SIL 3 - | IP RATING![]() IP65 IP67 IP69K |
CROSS SECTION | 50 x 55 mm |
SAFETY LEVEL![]() Type 4 - PL e - SIL 3 - | IP RATING![]() IP65 IP67 IP69K |
CROSS SECTION | 50 x 60 mm |
SAFETY LEVEL![]() Type 2 - PL c - SIL 1 - | IP RATING![]() IP65 IP67 IP69K |
CROSS SECTION | 30 x 28 mm |
SAFETY LEVEL![]() Type 2 - PL c - SIL 1 - | IP RATING![]() IP65 IP67 IP69K |
CROSS SECTION | 45 x 35 mm |
